Description
QUAD proudly announce Z Series, our new flagship ribbon loudspeaker range. After taking a new approach to ribbon tweeter design using a unique sandwich formation, an exceptionally robust, high power speaker has been engineered, yet with the delicate sound conventional ribbon speakers are known for. Z Series is housed beautifully curved piano lacquered cabinets, available in black, white and rosewood.
Technical Specifications
| General | Bookshelf Loudspeakers |
| Enclosure type | Bass Reflex |
| Transducer complement | 2-way |
| Bass driver | 150mm woven kevlar cone |
| Treble driver | 90x12mm true ribbon |
| AV shield | No |
| Sensitivity (1W @ 1m) | 86db |
| Recommended amplifier power | 40-150w |
| Peak SPL | 102dB |
| Nominal impedance | 8 |
| Minimum impedance | 4.6 |
| Frequency response (+/-3dB) | 56Hz – 20kHz |
| Bass extension (-6dB) | 48Hz |
| Crossover frequency | 3.4KHz |
| Cabinet Volume (in litres) | 10L |
| Dimensions | 383mm x 219mm x 283mm |
| Weight | 6.5kg |
| Finish | Piano Black / Piano White / Piano Rosewood |
| Accessories | User Manual, Certificate |
